RQA400ZY
RQA400ZY
RQA400ZY
|
Model |
Voltage (V) |
Frequency (HZ) |
Phase |
Inputpower (W) |
Current AMP |
Speed R/min |
Airflow M³/min |
Noise dB(A) |
Weight (kg) |
Capacitance (µF) |
Bearing Type |
|
RQA400ZY-4C |
110 |
50 |
1 |
180 |
1.50 |
1300 |
55 |
68 |
7.0 |
16µF/250V |
B |
|
RQA400ZY-4E |
220 |
50 |
1 |
180 |
0.80 |
1300 |
55 |
68 |
7.0 |
6.0µF/450V |
B |
|
RQA400ZY-4D |
380 |
50 |
3 |
180 |
0.40 |
1300 |
55 |
68 |
7.0 |
/ |
B |
|
RQA400ZY-4D1 |
380 |
50 |
1 |
180 |
0.45 |
1300 |
55 |
68 |
7.0 |
3.0µF/250V |
B |
●The insulation class of the RQA series axial fan motor is F, and the protection class of that is IP54. All the motors have thermal protector in the winding.
●Voltage: The voltage of the single phase motor is 220V/50HZ, and the voltage of the three phases motor is 380V/50HZ, We can also supply other fan motors with different voltages and frequencies ac-cording to clients, requirement.
●The standard length of the electrical wire on the fan is 1.5m, and we also supply the fan mo-tors with connection box for clints, choises.
●The applicable ambient temperature of the fan motors used in condenser is from 0℃ to +60℃. The applicable ambient temperature of the fan motors used in evaporator is -30℃ to 0℃.
●The average service life of motors is over 30000 hours.
ILLustration Of Model
