RQA250/S
RQA250/S
RQA250/S
RQA300/S
RQA300/S
RQA300/S
|
MODEL |
VOLITAGE |
FREQUENCY |
CURRENT |
POWER |
SPEED |
AIR VOLUME |
NOISE |
CAPACITOR |
AMBIENT TEMP |
PRESSURE |
BARING |
|
V |
Hz |
A |
W |
r/min |
M3/h |
dBA |
μF |
℃ |
Pa |
Style |
|
|
RQA250L4/S |
110 |
50/60 |
0.60 |
60 |
1350 |
1400 |
68 |
100 |
-20~65 |
53 |
B |
|
RQA250E4/S |
220 |
50/60 |
0.27 |
60 |
1375 |
1400 |
55 |
300 |
-20~65 |
40 |
B |
|
RQA250D4/S |
380 |
50/60 |
0.15 |
60 |
1375 |
1400 |
55 |
/ |
-20~65 |
40 |
B |
|
RQA300L4/S |
110 |
50/60 |
0.70 |
80 |
1350 |
1800 |
73 |
100 |
-20~65 |
62 |
B |
|
RQA300E4/S |
220 |
50/60 |
0.37 |
80 |
1360 |
1800 |
60 |
300 |
-20~65 |
49 |
B |
|
RQA300D4/S |
380 |
50/60 |
0.20 |
80 |
1360 |
1800 |
60 |
/ |
-20~65 |
49 |
B |
●The insulation class of the RQA series axial fan motor is F, and the protection class of that is IP54. All the motors have thermal protector in the winding.
●Voltage: The voltage of the single phase motor is 220V/50HZ, and the voltage of the three phases motor is 380V/50HZ, We can also supply other fan motors with different voltages and frequencies ac-cording to clients, requirement.
●The standard length of the electrical wire on the fan is 1.5m, and we also supply the fan mo-tors with connection box for clints, choises.
●The applicable ambient temperature of the fan motors used in condenser is from 0℃ to +60℃. The applicable ambient temperature of the fan motors used in evaporator is -30℃ to 0℃.
●The average service life of motors is over 30000 hours.
ILLustration Of Model
